SharkBite 3/4 in. MNPT X 3/4 in. D FNPT Stainless Steel Tank Booster

The Cash Acme Tank Booster combines a Thermostatic Mixing Valve (TMV), a Flexible Connector and a Water Heater Tee in one package and can effectively double a household’s hot water heater capacity while delivering hot water at safe temperatures in residential/commercial applications. Available in regular and “PRO” models, both versions of the TMV are factory set at 120 degree Fahrenheit (49 degree Celsius), but may be easily adjusted and can be used with Shark Bite Flexible Water Heater Connectors and Ball Valves for easy installation in systems using copper, CPVC or PEX tubing, no need for additional transition fittings.

Domestic and commercial hot water distribution

To control water temperature at the source of heat (hot water tank) or point-of-use (sinks, lavatories or bath tubs)

Approvals and listings ASSE 1017, ASSE 1070, CSA B125.3, NSF/ANSI 372, NSF/ANSI 61, Listed by ASSE, IAPMO

Enables you to double your hot water

Easy-to-install DIY project, no soldering or glue required

Protect your home from scalding by regulating output temperature to a safe 120 degree Fahrenheit

Allows water to be stored at 140 degree Fahrenheit, preventing the growth of bacteria

High-grade polymers, polished finish and generous water passages prevent scaling and liming build-up

Integrated non-return checks and filters on both inlets

NSF/ANSI 372;NSF/ANSI 61; Listed by ASSE, IAPMO

Features

Brand Name:SharkBite

Product Type: Tank Booster

Application: Water Heater

Application: Water Heater

Average Lead Content: Lead Free

Brand Name: SharkBite

Inlet Diameter: 3/4 inch

Material: Stainless Steel

Outlet Diameter: 3/4 inch

Packaging Type: Boxed

Inlet Fitting Type: MNPT

Outlet Fitting Type: FNPT
